8001 Resin

8001-Photosensitive Resin

Specially formulated for transparent component manufacturing, this high-performance clear resin achieves an impressive light transmittance of up to 90.8%, presenting crystal-clear visual effects. Its low-viscosity formula enables effortless layer curing, fast molding speed and low shrinkage deformation, ensuring excellent surface smoothness and stable dimensional accuracy. Equipped with robust strength, great toughness and 53°C heat resistance, it fully meets the production standards of transparent functional parts and various prototype models. Our flexible custom 3d printing service supports personalized 3d printing on demand to print 3d resin transparent parts of diverse specifications, and efficient rapid 3d printing greatly shortens product development cycles for designers and enterprises.



Product Specifications & Features

Price:From $0.3
Technology: SLA(stereolithography)
Color: Transparent, Translucent
Build time: 72 hours (Batch orders will be longer)
Tolerance : ±0.2mm or within 0.3%
Recommended wall thickness: > 0.8mm
Max build size : 780mm x 780mm x 530mm
Minimum build size : 5mm x 5mm x 5mm / 10mm x 2mm x 2mm
Heat deflection temp: 53℃
Strengths: Excellent strength and toughness, high precision, and good dimensional stability.
Weaknesses: May have slight bubbles or textures on the surface. Not suitable for outdoor use, high temperatures, strong sunlight, and UV light environments.
Applications: Structural verification of household appliances, automotive parts, digital and consumer electronic products. Suitable for general assembly parts, small functional components, and products with transparency requirements.
Notes:
For transparent 8001 Resin, sanding and oil spraying will be applied by default.
Bubbles or small holes on the surface could not be completely avoided, and complex structures are hard to be completely transparent. The printing effect may not fully meet optical experiment requirements.
For translucent 8001 Resin, supports removal by default, and no sanding process.



Mechanical Properties

Measurement
Test Method
Value
Hardness, Shore D ASTM D 2240 86
Flexural modulus, Mpa ASTM D 79OM 2,100
Flexural strength, Mpa ASTM D 79OM 86
Tensile strength, MPa ASTM D 638 48
Elongation at break ASTM D 638 12%
Water Absorption D570-98 0.48%
Impact strength notched Izod ASTM D256A 28 J/m
Heat deflection temperature, °C ASTMD648@66PSI 53°C
