Black Resin
Black Resin
Black resin is a high-performance matte black photosensitive material for SLA 3D printing. It features deep pure black color with uniform tone and delicate surface texture. Low shrinkage brings excellent dimensional stability and avoids warping or deformation. It owns high hardness, good rigidity and balanced toughness, delivering fine detail restoration for complex structures and thin-wall parts. Easy for post-processing such as sanding, polishing, painting and gluing. With stable temperature resistance, it is ideal for appearance models, functional components, consumer electronics housings, automotive prototypes and industrial verification parts. Not suitable for long-term outdoor, UV radiation and continuous high-temperature environments.
Product Specifications & Features
Price: Starting from $1.0
Technology: SLA (Stereolithography) 3D Printing Technology
Color:Black
Build Time: 72 hours for standard production orders. The manufacturing lead time will be reasonably extended for oversized components, bulky parts and large-batch high-volume orders to guarantee stable printing quality and precise details.
Tolerance: ±0.2mm for dimensional sizes within 100mm; ±0.3% tolerance for structural dimensions above 100mm
Recommended Wall Thickness: More than 0.8mm for stable molding and complete resin curing
Max Build Size: 780mm × 780mm × 530mm
Min Build Size: 5mm × 5mm × 5mm for regular solid structures; 10mm × 2mm × 2mm for ultra-thin and slender structural features
Heat Deflection Temperature (ASTM D 648 @66PSI): 54-65℃
Strengths: This black resin delivers premium matte black surface with extremely smooth texture without visible layer lines. It provides outstanding toughness and long-term service durability. Featuring low curing shrinkage, the material maintains excellent dimensional stability and minimizes warpage during mass production. With superior hardness and mechanical strength, this resin possesses reliable heat resistance that can continuously withstand ambient temperatures up to 65℃. The consistent material performance makes it highly suitable for batch processing and high-volume repetitive production of industrial parts.
Weaknesses: This black resin material is not applicable for long-term outdoor placement, continuous high-temperature working environments, direct intense sunlight exposure and ultraviolet radiation conditions, which may cause material aging, brittleness and performance degradation.
Applications: Widely utilized for master mold appearance inspection, conceptual design validation, conventional structural components and durable functional parts. It is commonly adopted in multiple industrial sectors including automotive industry, consumer electronics and other commercial manufacturing fields.
Mechanical Properties of of 3 black resin materials
Price: Starting from $1.0
Technology: SLA (Stereolithography) 3D Printing Technology
Color:Black
Build Time: 72 hours for standard production orders. The manufacturing lead time will be reasonably extended for oversized components, bulky parts and large-batch high-volume orders to guarantee stable printing quality and precise details.
Tolerance: ±0.2mm for dimensional sizes within 100mm; ±0.3% tolerance for structural dimensions above 100mm
Recommended Wall Thickness: More than 0.8mm for stable molding and complete resin curing
Max Build Size: 780mm × 780mm × 530mm
Min Build Size: 5mm × 5mm × 5mm for regular solid structures; 10mm × 2mm × 2mm for ultra-thin and slender structural features
Heat Deflection Temperature (ASTM D 648 @66PSI): 54-65℃
Strengths: This black resin delivers premium matte black surface with extremely smooth texture without visible layer lines. It provides outstanding toughness and long-term service durability. Featuring low curing shrinkage, the material maintains excellent dimensional stability and minimizes warpage during mass production. With superior hardness and mechanical strength, this resin possesses reliable heat resistance that can continuously withstand ambient temperatures up to 65℃. The consistent material performance makes it highly suitable for batch processing and high-volume repetitive production of industrial parts.
Weaknesses: This black resin material is not applicable for long-term outdoor placement, continuous high-temperature working environments, direct intense sunlight exposure and ultraviolet radiation conditions, which may cause material aging, brittleness and performance degradation.
Applications: Widely utilized for master mold appearance inspection, conceptual design validation, conventional structural components and durable functional parts. It is commonly adopted in multiple industrial sectors including automotive industry, consumer electronics and other commercial manufacturing fields.
Materials / Details |
Black Resin |
Imagine Black |
Black Resin |
| 3D Technology | SLA | SLA | SLA |
| Color | Grayish Black | Black | Black |
| General Build Time | 72h | 72h | 72h |
| Hardness (Shore D) | 78~88 | 79 | 78~85 |
| Tensile Modulus (MPa) | 2,649-2,731 | 2,370-2,650 | 2,649-2,731 |
| Tensile Strength (MPa) | 41-58 | 66.8-67.8 | 41-57 |
| Elongation At Break | 7-11% | 6-9% | 7-11% |
| Flexural Modulus (MPa) | 2,722-2792 | 2,178-2,222 | 2,711-2,789 |
| Flexural Strength (MPa) | 69-76 | 66.8-67.8 | 69-75 |
| Poisson's Ratio | 0.4-0.44 | 0.41 | 0.4-0.44 |
| Heat Deflection Temp | 58~69°C | 46°C | 54~65°C |
| Impact strength notched lzod | 29-34J/m | 23-29 kJ/㎡ | 29-34J/m |
| Dielectric Constant, 60Hz | 4.2~5.0 | 3.8 | 4.2~5.0 |
| Dielectric Constant, 1kHz | 3.3~4.2 | 3.7 | 3.3-4.2 |
| Dielectric Constant, 1MHz | 3.2~4.0 | 3.4 | 3.2~4.0 |
| Dielectric Strength, kV/mm | 12.8~16.1 | 17.9 | 12.8~16.1 |
