Services
We support 3D printing with various materials. Feel free to contact us or visit our factory.
🎁 New users only — Register now and get up to $20 coupons for your first orders!
ABS Plastic
Product Specifications & Features
Price: Our ABS Plastic 3D printing service starts at an affordable price of $3.00, delivering reliable, cost-effective solutions for both prototype development and low-to-medium volume production parts.
Technology: Manufactured using mature FDM (Fused Deposition Modeling) technology, a widely adopted industrial 3D printing process that ensures stable molding quality, consistent layer adhesion, and dependable mechanical performance.
Build time: The standard production lead time ranges from 72 to 96 hours. For batch orders, the manufacturing period will be extended by 1 to 3 additional days to guarantee consistent quality and precise execution.
Tolerance: Strict dimensional accuracy is maintained throughout production. The tolerance is ±0.3mm for dimensions ≤100mm, or within 0.4% for dimensions exceeding 100mm.
Wall thickness: Recommended minimum wall thickness is 1.6mm for optimal structural strength and print stability; the absolute minimum wall thickness is 1.2mm for lightweight or simplified designs.
Maximum build size: The maximum printable dimension is 580mm × 480mm × 480mm, supporting the production of large-scale functional components and assembly parts.
Heat deflection temp: Boasts a reliable heat deflection temperature of 98°C, ensuring stable structural integrity and consistent performance under elevated working temperatures.
Characteristics: Durable construction, excellent high-temperature resistance, balanced toughness, and reliable comprehensive mechanical properties. Features a natural textured surface typical of FDM printing. Ideal for manufacturing simple functional components and parts requiring thick wall sections.
Applications: Perfect for functional prototypes, low-to-medium volume production parts, automotive components, household appliances, and a wide range of general engineering applications.
Material Properties
Price: Our ABS Plastic 3D printing service starts at an affordable price of $3.00, delivering reliable, cost-effective solutions for both prototype development and low-to-medium volume production parts.
Technology: Manufactured using mature FDM (Fused Deposition Modeling) technology, a widely adopted industrial 3D printing process that ensures stable molding quality, consistent layer adhesion, and dependable mechanical performance.
Build time: The standard production lead time ranges from 72 to 96 hours. For batch orders, the manufacturing period will be extended by 1 to 3 additional days to guarantee consistent quality and precise execution.
Tolerance: Strict dimensional accuracy is maintained throughout production. The tolerance is ±0.3mm for dimensions ≤100mm, or within 0.4% for dimensions exceeding 100mm.
Wall thickness: Recommended minimum wall thickness is 1.6mm for optimal structural strength and print stability; the absolute minimum wall thickness is 1.2mm for lightweight or simplified designs.
Maximum build size: The maximum printable dimension is 580mm × 480mm × 480mm, supporting the production of large-scale functional components and assembly parts.
Heat deflection temp: Boasts a reliable heat deflection temperature of 98°C, ensuring stable structural integrity and consistent performance under elevated working temperatures.
Characteristics: Durable construction, excellent high-temperature resistance, balanced toughness, and reliable comprehensive mechanical properties. Features a natural textured surface typical of FDM printing. Ideal for manufacturing simple functional components and parts requiring thick wall sections.
Applications: Perfect for functional prototypes, low-to-medium volume production parts, automotive components, household appliances, and a wide range of general engineering applications.
Measurement |
Test Method |
Value |
| Heat deflection temperature | ISO 75 1.8MPa | 98°C |
| Flexural strength | ISO 178 | 65.5MPa |
| Flexural modulus | ISO 178 | 1,530MPa |
| Impact strength notched Izod | ISO 179 | 16.4KJ/m² |
| Hardness Shore D | ASTM D2240 | 65 |
| Young's modulus | ISO 527 | 1847MPa |
| Tensile strength | ISO 527 | 28.8MPa |
| Elongation at break | ISO 527 | 3.8% |
