Bakelite, chemically defined as phenolic plastic, is the world’s first thermosetting plastic material successfully applied to large-scale industrial manufacturing.
Get instant quote
Bakelite
Bakelite CNC Machining
Phenolic Resin Laminates CNC Processing
Bakelite, chemically defined as phenolic plastic, is the world’s first thermosetting plastic material successfully applied to large-scale industrial manufacturing, marking a milestone in the development of the modern plastics industry.
This industrial-grade thermosetting material features stable and reliable comprehensive performance. It delivers high mechanical strength with excellent structural rigidity, outstanding electrical insulation capability, reliable heat resistance, and superior chemical corrosion resistance. With these stable physical and chemical properties, Bakelite can maintain long-term stable operation in complex working environments and is not prone to deformation, aging or damage.
Benefiting from its excellent insulating and heat-resistant characteristics, Bakelite is widely manufactured into various electrical insulation components in factory production. Typical finished products include power switches, lamp bases, earphone shells, telephone housings, instrument enclosures and other electrical and electronic structural parts, which is why phenolic plastic is universally known as “Bakelite”. As the earliest industrially mass-produced plastic material, the popularization and application of Bakelite has effectively promoted the upgrading of industrial manufacturing processes and laid a solid foundation for the standardized production of electrical insulation parts, bringing far-reaching significance to the development of the modern industrial system.
This industrial-grade thermosetting material features stable and reliable comprehensive performance. It delivers high mechanical strength with excellent structural rigidity, outstanding electrical insulation capability, reliable heat resistance, and superior chemical corrosion resistance. With these stable physical and chemical properties, Bakelite can maintain long-term stable operation in complex working environments and is not prone to deformation, aging or damage.
Benefiting from its excellent insulating and heat-resistant characteristics, Bakelite is widely manufactured into various electrical insulation components in factory production. Typical finished products include power switches, lamp bases, earphone shells, telephone housings, instrument enclosures and other electrical and electronic structural parts, which is why phenolic plastic is universally known as “Bakelite”. As the earliest industrially mass-produced plastic material, the popularization and application of Bakelite has effectively promoted the upgrading of industrial manufacturing processes and laid a solid foundation for the standardized production of electrical insulation parts, bringing far-reaching significance to the development of the modern industrial system.
Bakelite Mechanical Properties
Phenolic plastic is classified as a rigid, brittle thermosetting material. Commonly known as Bakelite, it features non-water-absorbent, non-conductive, high-temperature resistant and high-strength properties, making it widely applied in electrical appliance manufacturing. The material is named “Bakelite” due to its excellent insulation performance and wood-like formability. Bakelite is produced by blending powdered phenolic resin with fillers such as wood powder, asbestos or clay, followed by high-temperature compression molding to form finished parts.
Typical characteristics of phenolic Bakelite include a hard surface, brittle texture, and a wood-board knocking sound when struck. It is mostly opaque with dark brown or black appearances and will not soften when immersed in hot water. As a reliable insulating material, its core chemical composition is phenolic resin.
Molding Process Performance
1. Phenolic plastic possesses favorable moldability. However, its molding shrinkage and directional shrinkage are generally higher than those of amino plastics. The material contains volatile moisture components, so preheating treatment is required before formal molding. Venting operations must be performed during the molding cycle. If preheating is omitted, appropriately increased mold temperature and molding pressure are necessary to ensure molding quality.
2. Mold temperature exerts a significant influence on the melt fluidity of phenolic plastic. Fluidity drops sharply when the mold temperature exceeds 160°C.
3. Compared with amino plastics, phenolic plastic has a relatively slower curing rate and releases large amounts of heat during the curing reaction. For large and thick-walled molded parts, excessive internal temperature is likely to occur, easily causing uneven curing and local overheating defects.
Resin Synthesis and Curing Mechanism
When the molar ratio of formaldehyde to phenol is less than 1, thermoplastic linear phenolic resin can be produced. This resin contains no further condensable active groups and cannot cure independently. It requires the addition of a curing agent and heating to complete cross-linking and curing. Taking hexamethylenetetramine as the curing agent with a curing temperature of 150°C, the resin mixed with fillers forms molding powder, which is commonly known as Bakelite powder.
When the molar ratio of formaldehyde to phenol is greater than 1, alkali-catalyzed reaction generates Stage A thermosetting phenolic resin. This resin is soluble in organic solvents and contains hydroxymethyl groups capable of further condensation cross-linking, enabling self-curing without additional curing agents. Upon heating, Stage A resin reacts to form Stage B resin (semi-soluble phenolic resin), which is insoluble and infusible but capable of swelling and softening. Further heating and reaction finally generate Stage C resin with a fully cross-linked bulk structure, featuring complete insolubility and infusibility. In addition, Stage A resin can undergo self-curing naturally during long-term storage.
Curing Types of Thermosetting Phenolic Resin
Thermosetting phenolic resin has two mainstream curing methods: room-temperature curing and thermal curing. For room-temperature curing, non-toxic NL room-temperature curing agent can be adopted. Benzene sulfonyl chloride or petroleum sulfonic acid are also optional curing agents, though these two materials have higher toxicity and obvious irritation.
