9600 Resin
9600 Resin - Photosensitive Resin
9600 Resin is an advanced high-performance UV-curable photosensitive resin professionally formulated for precise stereolithography 3d printing. The material delivers balanced mechanical performance combining exceptional strength, reliable toughness, ultra-smooth surface finish and ultra-fine detail resolution. With minimal curing shrinkage and excellent dimensional stability, it eliminates common deformation issues and ensures consistent part accuracy batch after batch. Ideal for sophisticated rapid prototyping 3d printing, high-standard appearance models, functional structural components, industrial design validation and reliable low-volume manufacturing. This premium resin 3d printing material consistently achieves high quality 3d printing results for rigorous industrial and commercial projects.
Upload your 3D printing files and get a quick quotation
Get Quote
Product Specifications & Features
Price: Starting from $0.3 per gram
Technology: SLA (Stereolithography)
Color: Matte White
Build Time: 48 hours (longer lead time applies for large-size parts, bulk or high-volume orders)
Tolerance: ±0.2mm for parts within 100mm; ±0.3% for parts over 100mm
Recommended Wall Thickness: > 0.8mm
Maximum Build Size: 780mm × 780mm × 530mm
Minimum Build Size: 5mm × 5mm × 5mm / 10mm × 2mm × 2mm
Heat Deflection Temperature (at 0.45 MPa): 59℃
Strengths
Matte white finish with fine, smooth surface texture; high toughness and excellent durability. Outstanding hardness and mechanical strength, with good heat resistance up to 59℃. Ideal for small-batch and mass production of functional parts.
Weaknesses
Not recommended for outdoor use, high-temperature environments, or long-term exposure to direct sunlight and UV radiation.
Applications
Widely used for manufacturing pipes, buckles, and electronic product housings. Perfect for structural & appearance verification, master molds, conceptual models, general parts, and functional components in industrial sectors including automotive and consumer electronics.
Mechanical Properties
Measurement |
Test Method |
Value |
| Tensile Strength | ASTM D638M | 55MPa |
| Tensile Modulus | ASTM D638M | 3200MPa |
| Elongation at Break | ASTM D638M | 5.50% |
| Flexural Strength | ASTM D790 | 81MPa |
| Flexural Modulus | ASTM D790 | 2600MPa |
| Izod Impact(Notched) | ASTM D256 | 32J/m |
| Water Absorption | ASTM D570 | 0.55% |
| Hardness(Shore D) | ASTM D2241 | 81D |
| HDT@0.45 MPa | ASTM D648 0.45 MPa | 59°C |
| HDT@1.82 MPa | ASTM D648 1.82 MPa | 53°C |
