Features |
Recommended Size |
| Minimum Build Size | 5mm*5mm*5mm |
| Maximum Build Size | Nylon PA12 - 370mm*276mm*360mm / Nylon PAC - 320mm*175mm*225mm |
| Recommended wall thickness | 1.0mm |
| Minimum Embossed & Engraved Details | 0.5 mm deep & 0.5 mm wide |
| Minimum Clearance (between parts that will be assembled together) | 0.2mm-0.4mm |
| Minimum Clearance (between two moving or connecting parts) | 0.6mm |
| Threads Design | Thread pitch - 0.6mm |
| Minimum Escape Hole Diameter | 2.5mm |
| Minimum Holes design | 1.5mm |
| Minimum column design | 2.0mm |
