Grey Resin

Grey Resin

Grey Resin is a rigid, multi-functional photosensitive resin with a standardized matte grey surface, widely used for industrial sample verification and small-batch production. It integrates high hardness, smooth surface finish and precise dimensional control, with stable mechanical properties and low shrinkage characteristics that effectively avoid part deformation. The material achieves even color distribution without granular texture, ensuring unified appearance standards for test pieces and formal parts. It supports full conventional post-processing processes such as polishing, sanding, painting and adhesive bonding, featuring excellent process adaptability. As a cost-effective universal material, it covers most application scenarios including engineering 3d printing prototype fabrication, mechanical parts manufacturing, casing design verification, industrial sampling and daily functional component production, perfectly matchingrapid prototyping and small-batch rapid manufacturing 3d printing demands via our professional resin 3d printing service.

Limitations: This general rigid resin cannot withstand long-term outdoor exposure, sustained high-temperature environments and persistent UV radiation, which will accelerate material aging, discoloration and structural performance degradation.



Product Specifications & Features

Price: Starting from $0.3
Technology: SLA (Stereolithography) 3D Printing Technology
Color: Grey
Build Time: 72 hours for standard orders. The manufacturing lead time will be appropriately extended for oversized components and large-batch mass production orders.
Tolerance: ±0.2mm for dimensions within 100mm; ±0.3% tolerance for structural sizes above 100mm
Recommended Wall Thickness: More than 0.8mm for stable printing and structural integrity
Max Build Size: 580mm × 580mm × 380mm
Min Build Size: 5mm × 5mm × 5mm / 10mm × 2mm × 2mm for ultra-small structural features
Heat Deflection Temperature (ASTM D 648 @66PSI): 59℃
Strengths: Featuring a uniform industrial grey appearance, this resin delivers high mechanical strength and excellent structural toughness. It maintains outstanding dimensional stability with low curing shrinkage during the printing process. The material possesses steady temperature resistance, which can withstand ambient temperatures up to 65°C. It is perfectly adapted to batch processing and high-volume repetitive production of industrial parts.
Weaknesses: This material is not applicable for long-term outdoor placement, persistent high-temperature working conditions, environments with direct sunlight exposure and intensive UV radiation.
Applications: Widely applied for master mold appearance verification, conceptual design models, conventional structural components, and functional testing parts. It covers multiple industrial sectors including automotive industry and consumer electronic equipment manufacturing.

Mechanical Properties

Measurement
Test Method
Value
Tensile Strength ASTM D638 41-61MPa
Tensile Modulus ASTM D638 2638-2675MPa
Elongation at Break ASTM D638 7-12%
Flexural Strength ASTM D790 69-77MPa
Flexural Modulus ASTM D790 2705-2875MPa
Hardness(Shore D) ASTM D2240 76-83
Poisson's Ratio ASTM D638 0.4-0.44
Impact strength notched Izod, J/m ASTM D256 36-55
Heat deflection temperature, (°C) ASTM D 648 @66PSI 51-59
Glass transition,Tg, (°C) DMA, E"peak 61-68
Coefficient of thermal expension, (°C) TMA(T<Tg) 90~103*E-6
Dielectric Constant 60 Hz ASTM D 150-98 4.2-5.0
Dielectric Constant 1kHz ASTM D 150-98 3.3-4.2
Dielectric Constant 1 MHz ASTM D 150-98 3.2-4.0
Dielectric Strength kV/mm ASTM D 1549-97a 12.8-16.1
